SWIFT · Sweden · Residential
SWIFT Pro
Fifty millimetres of pit, 2250mm of headroom, and a battery drive that keeps running through a blackout — the Swedish home lift that fits houses other manufacturers have already turned down.
On the showroom floor
This model is installed and running at Braeside — ride it before you commit.
maximum travel
up to
rated load
pit depth
single phase
With a battery drive and touch screen car operating panel, the luxurious SWIFT Pro is the most advanced residential lift available from the Swedish manufacturer. With SWIFT remote monitoring, there is no delay in reporting breakdowns or service requests, even though the unique Antitrap system maintains operation even in the event of mains power failure, ensuring you're never stuck.
Specification
- Drive System
- Battery / Screw & Nut
- Pit Depth
- 50mm
- Headroom
- 2250mm
- Power Supply
- Single Phase 240V
- Compliance
- AS1735.18
Brochure download asks for an email address first
Every angle, on your terms
Double glass doors open on a fully adjustable 180° swing, set individually for each blade. Built-in obstacle detection and a stay-open function make tight hallways and awkward entries a non-issue — with adjustable door speed to suit the room.
HoverTap the diagram to see the swing in action.
The numbers behind the ride
- Floors served
- 2–6 floors
- Travel
- 250mm – 15,000mm
- Speed
- Max 0.3 m/s (user-adjustable)
- Power supply
- 230V single-phase, 6A (8A fuse)
- Drive system
- Patent-pending screw & nut drive
- Installation
- 50mm recessed, in line with the floor — or on top of the floor with a ramp
- Handrail
- Black or white
- Lighting
- White LED carrier; white or coloured LED shaft & ceiling
Six sizes, one floor opening
| Model | Size | Rated load | Hole through floor* |
|---|---|---|---|
| XXS | 830 × 600 mm | 250kg / 2 persons | 940 × 1025 mm |
| XS | 830 × 850 mm | 250kg / 3 persons | 940 × 1275 mm |
| S | 830 × 1000 mm | 250kg / 3 persons | 940 × 1425 mm |
| M | 830 × 1100 mm | 250kg / 3 persons | 940 × 1525 mm |
| L | 1200 × 1000 mm | 400kg / 5 persons | 1310 × 1425 mm |
| XL | 1400 × 1100 mm | 400kg / 5 persons | 1510 × 1525 mm |
*Recommended size for the floor opening.
Ride this one in Braeside
You can't judge a lift from a PDF. Four of them are installed and running at 2/226 Governor Rd, Braeside.
