SWIFT · Sweden · Residential
SWIFT Lite
The same Swedish battery drive and 50mm pit as the Pro, with a traditional push button panel — the more affordable way into a luxury home lift.
maximum travel
up to
rated load
pit depth
single phase
Equiped with a traditional push button operating panel, the SWIFT Lite is the Swedish manufacturer's more affordable option without compromsing on the key features you want in a luxury home lift.
Specification
- Drive System
- Battery / Screw & Nut
- Pit Depth
- 50mm
- Headroom
- 2250mm
- Power Supply
- Single Phase 240V
- Compliance
- AS1735.18
Brochure download asks for an email address first
Every angle, on your terms
Double glass doors open on a fully adjustable 180° swing, set individually for each blade. Built-in obstacle detection and a stay-open function make tight hallways and awkward entries a non-issue — with adjustable door speed to suit the room.
HoverTap the diagram to see the swing in action.
The numbers behind the ride
- Floors served
- 2–6 floors
- Travel
- 250mm – 15,000mm
- Speed
- Max 0.3 m/s (user-adjustable)
- Power supply
- 230V single-phase, 6A (8A fuse)
- Drive system
- Patent-pending screw & nut drive
- Installation
- 50mm recessed, in line with the floor — or on top of the floor with a ramp
- Handrail
- Black or white
- Lighting
- White LED carrier; white LED shaft & ceiling
Six sizes, one floor opening
| Model | Size | Rated load | Hole through floor* |
|---|---|---|---|
| XXS | 830 × 600 mm | 250kg / 2 persons | 940 × 1025 mm |
| XS | 830 × 850 mm | 250kg / 3 persons | 940 × 1275 mm |
| S | 830 × 1000 mm | 250kg / 3 persons | 940 × 1425 mm |
| M | 830 × 1100 mm | 250kg / 3 persons | 940 × 1525 mm |
| L | 1200 × 1000 mm | 400kg / 5 persons | 1310 × 1425 mm |
| XL | 1400 × 1100 mm | 400kg / 5 persons | 1510 × 1525 mm |
*Recommended size for the floor opening.
Ride one in Braeside
You can't judge a lift from a PDF. Four of them are installed and running at 2/226 Governor Rd, Braeside.
